Product Designer’s 100 LED Display Application Analysis｜Home Appliances (1) #1~10
This article belong to [Product Designer’s 100 LED Display Application Analysis] series, was written by OPTO PLUS LED Corp. We will analysis and classify all product that use LED display. Any Product designer want to use LED display to it’s product can banefit by our application analysis. Our article collect and analysis how LED dispay will display in other product and product designer can choose the lower cost and most suitable it’s own product design.
- Product Designer’s 100 LED Display Application Analysis | home appliances(1) #1~10
- Product Designer’s 100 LED Display Application Analysis | home appliances(2) #11~25
- Product Designer’s 100 LED Display Application Analysis | home appliances(3) #26~35
- Product Designer’s 100 LED Display Application Analysis | Consumer Electronics(1) #36~45
- Product Designer’s 100 LED Display Application Analysis | Consumer Electronics(2) #46-60
- Product Designer’s 100 LED Display Application Analysis | Display product (1) #61-75
- Product Designer’s 100 LED Display Application Analysis | Game console (1) #76-85
- Product Designer’s 100 LED Display Application Analysis |Electrical Instrument1) #86-100
LED Display Application Analysis｜Home Appliances#01｜pourx oura coffee scale
- Product application：
- Display weight and time , coffee brewing step by step guide
- Referencd Video﹕
- Which LED display were used：
- A：Display characters
- 5 white color 7-segment (small size SMD Package 7-segment LED standard Display?) to display Weight
- C：LED Guide light :
- LED Guide light: Use PLCC Package RGB LED or SMD package RGB LED
- Outer light =coffee brewing step by step guide
- Inner LED Guide light =Mode select
- A：Display characters
- Emitting color ：
- Characters and Inner LED Guide light : White color
- Outer light: RGB LED
LED Display Application Analysis｜Home Appliances#02｜coffee grinder
- Product application：
- Coffee grinder count
- Reference Picture﹕
- Which LED display were used：
- A：Display characters
- use for 4 digit red color 7-segment display :Coffee grinder count
- A：Display characters
- Emitting color ：
- red color
LED Display Application Analysis｜Home Appliances#03｜coffee machine
- Product application：
- show the size of coffee
- Reference Picture﹕
- Which LED display were used：
- C：LED Guide light :
- Use SMD LED or LED LED LAMP to show coffee size are L size or S size
- C：LED Guide light :
- Emitting color ：
- Blue color
LED Display Application Analysis｜Home Appliances#04｜ACAIA PERAL Model S coffee scale
- Product application：
- Show the countdown timer ,weight, characters.
- Referencd Video and picture﹕
- Which LED display were used：
- Product use full custiom LED dot matrix display to show white dotmatirx and LED guide light.
- B：Display graphics / dot matrix
- 5*44 white color dot matrix
- C：LED Guide light :
- 2 orange Guide light, 2 orange Guide light, to show coffee scale mode.
- Emitting color ：
- White color/ Green color / Orange color
LED Display Application Analysis｜Home Appliances#05｜ACAIA PEARL coffee scale
- Product application：
- Show the countdown timer ,weight, characters.
- Referencd Video and picture﹕
- Which LED display were used：
- Product use full custiom LED dot matrix display to show white dotmatirx and LED guide light.
- A：Display characters
- 8 digit white color 7-segment display
- C：LED Guide light :
- 37 White color LED Guide light to show the coffee brewing speed
- coffee brewing speed demo video︰
- both side have 4 White color LED Guide light to show the coffee scale ‘s mode
- Emitting color ：
- White color
LED Display Application Analysis｜Home Appliances#06｜bodyweight scale
- Product application：
- bodyweight scale
- Referencd Video and picture:
- Product page:
- Product Demo:
- Which LED display were used：
- Product use full custiom LED 7-segment display and LED guide light.
- A：Display characters
- 4 White color 7-segment display
- C：LED guide light
- 2 LED guide light to show KG /LBS
- Emitting color ：
- White color
LED Display Application Analysis｜Home Appliances#07｜Smart kitchen scale
- Product application：
- To display weight of food
- Referencd Video and picture:
- Product page:
- Which LED display were used：
- Product use full custiom LED 7-segment display and LED guide light.
- A：Display characters
- White color 7-segment dispaly to show food weight and pluse minus symbol
- C：LED guide light
- 5 white LED guide light to smart kitchen scalemode
- Emitting color ：
- White color
LED Display Application Analysis｜Home Appliances#08｜Air conditioner temperature controller
- Product application：
- To display Air conditioner temperature and Air conditioner mode
- Reference Picture﹕
- Which LED display were used：
- A：Display characters
- 2 set 2 digit 2 digit green color standard mid size 7-segment display
- C：LED guide light
- 3 red color LED Lamp guide light and five green LED lamp guide light
- A：Display characters
- Emitting color ：
- red color /green color
LED Display Application Analysis｜Home Appliances#09｜NIX｜4 in 1 Micro smart washing machine
- Product application：
- washing machine dashboard :To display washing time
- Referencd Video and picture:
- Product page:
- Which LED display were used：
- Product use full custiom LED 7-segment display and LED guide light.
- A：Display characters
- C：LED guide light
- 2 white color LED Lamp guide light
- Emitting color ：
- White color
LED Display Application Analysis｜Home Appliances#10｜Air conditioner dashboard
- Product application：
- To display Air conditioner tempture and mode select
- Reference Picture﹕
- Which LED display were used：
- A：Display characters
- C：LED guide light
- use 8 blue color LED Lamp guide light to show Air conditioner’s mode
- Emitting color ：
- Blue color
